MITSU 30k UNIVERSAL OUTDOOR R410A

Mitsubishi Ductless>M Series Outdoor Units>SUZ Single Zone Heat Pump>MITSU 30k UNIVERSAL OUTDOOR R410A

MITSU 30k UNIVERSAL OUTDOOR R410A

Product #: SUZ-KA30NA2.TH

Volume: 14.72
Weight: 86

Description

Features & Benefits

  • Significant energy savings up to 30%
  • Auto change over between cooling and heating
  • Extreme quiet operation as low as 23 dB(A)
  • Ultra thin profile only 7-7/8 Inch high
  • Adjustable ESP to meet different layouts
  • Built-in high performance drain pump
  • Pre charged refrigerant
  • Long pipe runs up to 100 ft
  • 65 ft refrigerant pipe length
  • 40 ft refrigerant pipe height difference

Product Specifications

  • Item: Heat Pump
  • Type: Split System, Outdoor
  • Series: SUZ
  • Tons of Refrigeration (TR): 1.5 ton
  • Cooling Capacity: 15000 BTU/hr
  • Heating Capacity: 18000 BTU/hr
  • SEER Rating: 16
  • EER Rating: 10.2
  • HSPF Rating: 9.6
  • Coefficient of Performance (COP) Heating: 2.71 at 47 deg F, 1.99 at 17 deg F
  • Compressor Type: DC Inverter Driven Twin Rotary
  • Blower Motor Specifications: 0.28 FLA, 20 W
  • Flow Rate: 250/290/350 cfm (Low/Med/High)
  • Refrigerant Type: R-410A
  • Refrigerant Piping: 1/4 Inch Liquid Line, 1/2 Inch Suction Line
  • Noise Level: 40 dBA
  • Power Supply: 1-Ph, 208 - 230 VAC
  • Minimum Circuit Ampacity: 12 A
  • Maximum Circuit Protection: 15 A
  • Connection Type: Flared
  • Dimensions: 31-1/2 Inch Width x 11-1/4 Inch Depth x 21-5/8 Inch Height
  • Standards/Approvals: AHRI Certified, cUS, ETL Listed
