Platinum Condensing Gas Furnaces
- Comfort-R enhanced mode (cooling)
- AccuLink system (field-configurable to 24V non-communicating mode)
- Meets requirements for 2% or less air leakage
- Adjustable heating fan off timing
- Blower door safety switch
- Cleanable/reusable high-velocity filters
- Complete front service access
- Dual PVC pipe venting (1- or 2-pipe option)
- Modulating gas valve and regulator
- Heavy-gauge reinforced wrap-around steel cabinet
- Humidifier/EAC hook-up capability
- Insulated blower compartment (4) sides
- Integrated solid-state control with self-diagnostics
- Left/right condensate drain capability in vertical application
- Service diagnostics with faults reported at the user interface
- Lite Port/Stored diagnostics
- Manual reset flame roll-out switches
- Multi-port inshot burners
- Painted cabinet with 2-tone color
- Silicon nitride hot surface igniter
- Slide-out blower assembly with direct drive, variable-speed blower motor
- Solid burner door (quiet operation)
- 20 Gauge aluminized steel heat exchanger and Type 29-4C stainless steel secondary heat exchanger
- 24V Secondary fuse
- Variable-speed venter motor
- Electrical: 115-1-60
- Certified to ANSI Z21.47/CSA 2.3
- AHRI Certified
- Energy Star? rated
- cETLus Listed
- Lifetime registered limited warranty on heat exchanger
- 10-Year registered limited warranty on all other functional parts
- Extended warranties available
- Residential warranty terms require registration within 60 days of installation
Platinum 95 Upflow/Horizontal Left Modulating Communicating ECM Condensing Gas Furnace
- Alternate bottom/left/right return air
- Bottom panel
- Gasketed blower door
- Side return duct starter tabs
,
